형식 ( Model )
MT-100A
MT-125A
MT-150A
MT-100B
MT-125B
MT-150B
정격용량
(Rated Capacity)
KVA
100
125
150
1차입력전압
(Primary Input Voltage)
V
1φ 220 or 440
2차출력전압
(Second Output Voltage)
V
6.6 ~ 8.9
8.6 ~ 11.5
10.5 ~ 13.0
주파수
(Frequency)
Hz
50 or 60
조정단수
(Number of Taps)
-
4 Tap + OFF
중량
(Weight)
Kg
100
123
150
